The global meter view to the right of the interface works as a classic level indicator or can be used in time graph mode. The main waveform window has controls that allow you to zoom in and out, position the view and normalize the display so that the waveform will always fill the whole area vertically. This helps ignore irrelevant signals and improves detection. In testing, this appeared to work like magic when put on a variety of different audio sources by successfully locking onto the waveform with no additional mucking around required! If this is not working as expected you can use the Detector Panel to control the maximum and minimum detection thresholds to limit the frequencies in which the detector operates. The main standout feature of this VST is the built-in pitch detector. The controls themselves look simplistic at first glance, but this appearance belies some pretty powerful functionality. All sections of the interface have tool tips which helpfully explain all the control options.
#SMEXOSCOPE PROFESSIONAL#
It has a professional uncluttered looking User Interface which has a premium feel to it, and the UI is also completely resizable.
#SMEXOSCOPE FREE#
MOscilloscope is free as part of the MFreeFXBundle.
#SMEXOSCOPE PC#
S(M)exoscope is available to download for both PC and Mac. Based on where you place a marker on the display, the tool can be used to calculate waveform amplitude, length and frequency. In addition to these features, S(M)exoscope includes an excellent waveform analysis tool. Free mode with no re-triggering is selected by default.Īt the bottom of the control panel are four further option buttons: Sync Redraw which controls how quickly the display refreshes, Freeze which freezes the display, DC-Kill to compensate for DC offset, and Channel to toggle between the right and left audio channel.
Internal mode resets the display at a frequency determined by the internal trigger speed control knob. Rising and Falling modes retrigger the display each time a waveform peak passes above or below the level set by the retrigger threshold knob. Starting at the top, the display controls allow you to adjust the display time and waveform amplitude.įour different retrigger modes (Rising, Falling, Internal, Free) can be easily selected via the display mode button. It has a clear, attractive (if you like orange) interface with a large waveform display area and various intuitive controls located on the right-hand side. S(M)exoscope by Smartelectronix is one of the more popular free Oscilloscope VSTs around, and from first impressions it’s easy to see why.
